MS Flanges Table E
Slip On Flange Table E
Mild Steel · BS-10 Table E / F · 14 sizes
MS Flanges Table E
Flange Slip On Flange Table E
7307MS10TESO01
- Material
- Mild Steel (IS 1239 Part 2 / IS 2062 Gr. A)
- Type
- Forged / Fabricated
- Facing
- Flat Face
- Dimension Standard
- BS-10 Table E
- Temperature
- -10 deg C to 200 deg C
- Pressure Rating
- ~16 bar (BS-10 Table E)
- HSN Code
- 73079100
- GST
- 18%
Illustration7 columns · scroll sideways
Pricing: prices for this product are not listed. Request a quotation.
- Certification
- All relevant test certificates provided.
- Coating
- Anticorrosion Paint Included. GI / Epoxy extra.
- Taxes & Duties
- GST and all applicable levies charged extra at prevailing rates.
All dimensions in millimetres. Subject to change without notice. Spotted a mistake or wrong data? Please contact us.
Applicable Standards
Standards governing design, dimensions, and testing
BS-10
British Standard – Flanges and Bolting for Pipes, Valves and Fittings
The dominant flange standard in India for water, HVAC, and general utility service. Widely used on government tenders and municipal infrastructure projects.
- Table D: ~10 bar (the most common table in India)
- Table E: ~16 bar (medium pressure)
- Table F: ~25 bar (higher pressure)
- Flat face (FF) with full-face gasket is the default
- Bolt pattern and PCD differ from ASME B16.5: not interchangeable
- Material: IS 2062 Gr. A / mild steel standard
More in BS-10 Table E / F
