Hygienic SMS
Hygienic SMS End Cap
7307SMS1145EC01
- Material
- Stainless Steel 304L / 316L (ASTM A270)
- Type
- Precision Machined
- Surface finish
- Ra ≤ 0.8 μm
- End Connection
- SMS 1145 Union
- Dimension Standard
- SMS 1145
- Temperature
- -10 deg C to 130 deg C
- Pressure Rating
- Up to 6 bar
- HSN Code
- 73072990
- GST
- 18%
5 columns · scroll sideways
Pricing: prices for this product are not listed. Request a quotation.
- Certification
- Surface finish cert (Ra <= 0.8 um).
- Coating
- Ra <= 0.8 um internal polish.
- Taxes & Duties
- GST and all applicable levies charged extra at prevailing rates.
All dimensions in millimetres. Subject to change without notice. Spotted a mistake or wrong data? Please contact us.
Applicable Standards
Standards governing design, dimensions, and testing
SMS 1145
Dairy Pipe Couplings: Swedish Standard (SMS 1145)
Swedish standard for threaded hygienic pipe couplings (unions) on stainless steel tube, widely used in Scandinavian dairy, brewing and food plants.
- Union of a male part, a nut and a seal ring: opened without cutting the line
- Sized by tube outside diameter; confirm the tube series and wall with the order
- Not directly interchangeable with DIN 11851 or IDF unions
