Fortune Fittings Private Limited

Olets MSS SP-97

Elbolet

Olet Fittings · MSS SP-97 · 17 sizes

Request a quote for this item
← All Weldolet / Sockolet / Threadolet

Olets MSS SP-97

Olet Elbolet

7307OL9700-ELB-01

Material
Carbon Steel (ASTM A105N)
Type
Forged
Schedule
Matches run pipe schedule
End Connection
Butt Weld on Elbow
Dimension Standard
MSS SP-97
Temperature
-29 deg C to 427 deg C
Pressure Rating
Matches run pipe schedule rating
HSN Code
73079300
GST
18%
Schematic: letters match the table columns
Illustration of a elbolet (forged fittings), on a light grey backgroundIllustration

6 columns · scroll sideways

SizeNPSBase OD (D)mmHeight (H)mmWall (t)mmEnd TypeWeightkg
3/4 x 1/2 NB52408Butt Weld on Elbow0.17
1 x 1/2 NB58458Butt Weld on Elbow0.22
1 x 3/4 NB58459Butt Weld on Elbow0.22
1-1/2 x 1 NB735210Butt Weld on Elbow0.32
2 x 3/4 NB85609Butt Weld on Elbow0.43
2 x 1 NB856010Butt Weld on Elbow0.43
2 x 1-1/2 NB856012Butt Weld on Elbow0.43
3 x 1 NB1147010Butt Weld on Elbow0.92
3 x 1-1/2 NB1147012Butt Weld on Elbow0.92
3 x 2 NB1147014Butt Weld on Elbow0.92
4 x 1 NB1408510Butt Weld on Elbow1.14
4 x 2 NB1408514Butt Weld on Elbow1.14
4 x 3 NB1408510Butt Weld on Elbow1.14
6 x 2 NB19310014Butt Weld on Elbow2.72
6 x 4 NB19310010Butt Weld on Elbow2.72
8 x 4 NB24412010Butt Weld on Elbow4.36
8 x 6 NB24412010Butt Weld on Elbow4.36

Pricing: prices for this product are not listed. Request a quotation.

Certification
MTR, PMI, dimensional test certificates available.
Coating
Black paint / mill finish.
Taxes & Duties
GST and all applicable levies charged extra at prevailing rates.

All dimensions in millimetres. Subject to change without notice. Spotted a mistake or wrong data? Please contact us.

Applicable Standards

Standards governing design, dimensions, and testing

MSS SP-97

Integrally Reinforced Forged Branch Outlet Fittings – Socket Welding, Threaded, and Buttwelding Ends

Covers Weldolet, Sockolet, Threadolet, Elbolet, Nipolet, and Latrolet branch connection fittings. Self-reinforcing; no separate reinforcement pad needed within rating tables.

  • Weldolet: butt weld branch (no fillet); highest integrity
  • Sockolet: socket weld branch
  • Threadolet: threaded branch
  • Elbolet: branch on elbow (for pig traps and instrumentation)
  • Nipolet: integrated nipple for vent/drain without extra coupling
  • Run-to-branch ratio determines reinforcement adequacy
